Price: call us or send an enquiry
Availability: in stock
| Class of excavator | 12-17 t |
| Height H | 830 mm |
| Length | 890 mm |
| R | 660 mm |
| Width L | 1400 mm |
| Capacity | 0,35 m3 |
| Weight | 355 kg |
Applied materials and components
| 1. Bottom | 09Г2С | 8 mm |
| 2. Blade | 09Г2С | 30 mm |
| 3. Side wall | 09Г2С | 8 mm |
| 4. Wing | 09Г2С | 20 mm |
| 5. Ребро | 09Г2С | 10 mm |
| 6. Runner | 09Г2С | 8 mm |
| 7. Pipe | 159х14 | |
| 8. Beam | 09Г2С | 10 mm |
| 9. Eye (Lifting eye / Lifting lug) | 09Г2С | 20 mm |
