Price: call us or send an enquiry
Availability: in stock
| Class of excavator | 18-23 t |
| Height H | 920 mm |
| Length | 1020 mm |
| R | 780 mm |
| Width L | 1600 mm |
| Capacity | 0,52 m3 |
| Weight | 560 kg |
Applied materials and components
| 1. Bottom | 09Г2С | 10 mm |
| 2. Blade | 09Г2С | 30 mm |
| 3. Side wall | 09Г2С | 8 mm |
| 4. Wing | 09Г2С | 20 mm |
| 5. Ребро | 09Г2С | 16 mm |
| 6. Runner | 09Г2С | 8 mm |
| 7. Pipe | 180х16 | |
| 8. Beam | 09Г2С | 12 mm |
| 9. Eye (Lifting eye / Lifting lug) | 09Г2С | 25 mm |
