Price: call us or send an enquiry
Availability: in stock
| Class of excavator | 39-45 t |
| Height H | 1700 mm |
| Length | 1950 mm |
| R | 1400 mm |
| Width L | 1800 mm |
| Capacity | 2,3 m3 |
| Weight | 2580 kg |
| Bucket teeth quantity | 5 pcs. |
Applied materials and components
| 1. Bottom | HB-450 | 12 mm |
| 2. Blade | HB-360 | 50 mm |
| 3. Side wall | 10ХСНД | 12 mm |
| 4. Wing | HB-400 | 40 mm |
| 5. Side reinforcing plate | HB-450 | 12 mm |
| 6. Runner | HB-500 | 20 mm |
| 7. Beam | 10ХСНД | 25 mm |
| 8. Eye (Lifting eye / Lifting lug) | 10ХСНД | 40 mm |
| 9. Heel | HS175-140 | 12 pcs. |
| 10. Протектор/бокорез | 1U0740 | 4 pcs. |
| 11. Teeth | Esco U45C, Hehsley XS40RC, 9W8452RC, MG55E 208 | |
| 12. Межзуб. защита | 209-939-5170-140 или 4ML50UC | |
| 13. Side reinforcing plate | HB-450 | 12 mm |
| 14. Liner внутренняя | HB-450 | 8 mm |
| 15. Side reinforcing plate | HB-450 | 8 mm |
| 16. Защита БХЧ | h | 25 mm |
| 17. Side reinforcing plate | HB-450 | 12 mm |
