Price: call us or send an enquiry
Availability: in stock
| Class of excavator | 45-55 t |
| Height H | 1800 mm |
| Length | 2100 mm |
| R | 1500 mm |
| Width L | 1600 mm |
| Capacity | 2,25 m3 |
| Weight | 2850 kg |
| Bucket teeth quantity | 4 (5 шт при адаптерах J550) pcs. |
Applied materials and components
| 1. Bottom | HB-450 | 15 mm |
| 2. Blade | HB-360 | 60 mm |
| 3. Side wall | 10ХСНД | 12 mm |
| 4. Wing | HB-400 | 40 mm |
| 5. Side reinforcing plate | HB-450 | 12 mm |
| 6. Runner | HB-500 | 20 mm |
| 7. Beam | 10ХСНД | 25 mm |
| 8. Eye (Lifting eye / Lifting lug) | 10ХСНД | 40 mm |
| 9. Heel | HS 230-190 | 10 pcs. |
| 10. Протектор/бокорез | 1U0740 | 4 pcs. |
| 11. Teeth | Esco U55C, Hehsley XS50RC, 9W8552RC, MG55E | |
| 12. Межзуб. защита | 209-939-5170-140 или 4ML50UC | |
| 13. Side reinforcing plate | HB-450 | 15 mm |
| 14. Liner внутренняя | HB-450 | 8 mm |
| 15. Side reinforcing plate | HB-450 | 8 mm |
| 16. Защита БХЧ | h | 50 mm |
| 17. Side reinforcing plate | HB-450 | 15 mm |
