Price: call us or send an enquiry
Availability: in stock
| Class of excavator | 5-11 t |
| Height H | 900 mm |
| Length | 930 mm |
| R | 750 mm |
| Width L | 400 mm |
| Capacity | 0,12 m3 |
| Weight | 145 kg |
| Bucket teeth quantity | 3 pcs. |
Applied materials and components
| 1. Blade | 09Г2С | 20 mm |
| 2. Wing | 09Г2С | 16 mm |
| 3. Bottom | 09Г2С | 6 mm |
| 4. Side wall | 09Г2С | 6 mm |
| 5. Liner | 09Г2С | 6 mm |
| 6. Beam | 09Г2С | 6 mm |
| 7. Pipe | Сталь 20 | 102х22 mm |
| 8. Central Tooth | 85811440 (6Y6335-19) | |
| 9. Left Tooth | 85801377(E29R) | |
| 10. Right Tooth | 85801376(E29L) | |
