Price: call us or send an enquiry
Availability: in stock
Class of excavator | 5-11 t |
Height H | 900 mm |
Length | 930 mm |
R | 750 mm |
Width L | 650 mm |
Capacity | 0,23 m3 |
Weight | 190 kg |
Bucket teeth quantity | 4 pcs. |
Applied materials and components
1. Blade | 09Г2С | 20 mm |
2. Wing | 09Г2С | 16 mm |
3. Bottom | 09Г2С | 6 mm |
4. Side wall | 09Г2С | 6 mm |
5. Liner | 09Г2С | 6 mm |
6. Beam | 09Г2С | 6 mm |
7. Pipe | Сталь 20 | 102х22 mm |
8. Central Tooth | 85811440 (6Y6335-19) | |
9. Left Tooth | 85801377(E29R) | |
10. Right Tooth | 85801376(E29L) |
